Improove Your Home Design With Modular Rangehood:

Want to Know about chimney repair charge in NCR

Which One we should selct
There are few thing to consider while installing a smart Kitchen.

1. Select the best range hood for your smart kitchen.
2. Trust a expert and experienced on jbo professional.
3. Always choosethe best brands in market.

The kitchen hood is an important factor that you need to think about while installing. These can be primarily categorized as ducted and ductless or recycling chimneys.
In Ducted kitchen hoods, a duct pipe is fixed to the chimney that takes away the heat, odor, smoke, and another small molecule out of the kitchen But in case of ductless or recycling chimneys, smoke, odor, and other impurities get filtered and fresh air is circulated back into the kitchen.

While installing chimney we consider two chimney mostly.

1. Ducted Chimney
2. Ductless chimney

Ducted chimneys have been observed to be more effective, ductless chimneys have to be installed in homes where there’s no space for duct chimneys to install. Ultimately, which one you go for will depend on your range and kitchen setup, but you need to make the best choice as well.
Kitchen chimneys extract heat, smoke, food odors, and airborne grease with the help of their internal fan and filter. Ducted chimneys use a duct to transfer the stale air from the chimney and release it to the out. However, ductless or recycling chimneys take in the stale air and purify it by advancing it through a set of charcoal filters. The purified air is then circulated back into the kitchen.
In India, the style of cooking includes frying and use of ground spices, ducted chimneys work well as compare to ductless chimneys. Several options of the chimney to choose from according to the kitchen design and preference & style of cooking, define as the under-cabinet kitchen chimney, a wall-mounted kitchen chimney, or a ceiling-mounted chimney.

Some important factors to keep in mind are.

1.Chimney Size

60 cm or 90 cm is the standard width in which ducted chimneys are available. If the cooktop has 2 to 4 burners, going for a 60-cm-wide chimney works well enough. However, if you need a chimney for a cooktop with three or five burners, it is recommended to go for a 90-cm-wide chimney.
It is important the size of the chimney must always be slightly bigger than the size of the cooktop or of the same size. This ensures that the chimney sucks up all the fumes without letting them escape into the kitchen.

2. Chimney Filter

Two types of chimney filter are available – cassette filter and baffle filter.

1. Cassette Filter:

   The Cassette filter has numerous layers of metal mesh to accumulate the oil, grease and other kitchen pollutants, and release the smoke through a duct or a PVC pipe. However, it comes with a drawback. The cassette filter tends to clog up with the kitchen pollutants from time to time, and the suction power of the chimney subsides.

2. Baffle Filter:

   The Baffle Filter, on the other hand, has steel and aluminum layers that overlap with each other and change the direction of airflow. Baffle filters use ‘cut and chop’ technology to separate the grease from the smoke, and their suction capacity doesn’t decrease over time due to clogging.
3. Note: Only ductless chimneys have carbon filters. Grease and charcoal filters clean the air further before releasing it back into the kitchen.
   Besides, these filters need a lot of maintenance and also have to be replaced every three to six months.

3. Chimney Suction Power

Choosing a chimney with the right suction power is very necessary. The suction power of a chimney is measured in cubic meter/hour, and for the Indian style of cooking, it is suggested to choose with a power range of around 400 to 1000 cubic meters/hour depending on the size of your home kitchen.

4. Chimney Duct Capacity

The duct size and number of turns or bends in ducts is an important factor to consider. If the duct size is bigger then make sure the suction power of these chimneys is relatively more. The suction needs to be high for the smoke and other impurities to move out completely from the kitchen so that air remains in the kitchen should be clean. The length of the chimney duct should not exceed more than twelve feet make sure the chimney is positioned in a way that the pipe connecting to the outdoors is short so that the air suction power of the chimney can deliver maximum efficiency. In most Modern kitchens you will find a window or say a wall which has some hindrance because of which you have to install the chimney further away. This certainly drops the performance of the chimney.
Most people like stainless steel for the chimney duct pipes because it is durable and offers good resistance to corrosion. PVC and aluminum can be used for chimney ducts. It is good to keep the bends in the chimney duct to a maximum of two as shorter pipes with fewer bends work more effectively than a long pipe with more bends.

5. Cut-out for chimney Duct in the External Wall

Make a 6-inch-wide circular cut-out in the external wall for the chimney duct. Also, the cut-out needs to be made on the external wall such that the chimney height in the kitchen is seven feet from the floor level or above the window-lintel level. In case your kitchen doesn’t already have a circular cut-out, get the job done by a chimney installer. They can make the hole in the correct position of the external wall and install the chimney. You could also use the cut-out or position of the external exhaust fan for passing the chimney pipe through it. However, if you are living in a rented apartment or building with restrictions, going with a ductless model is the only option.

6. Height of Chimney From Kitchen Platform

The distance of the chimney from stove or countertop must fall within the range of 26 to 30 inches.No matter what type of cooking range you have, like an electric cooking range, built-in hob, or a usual cooktop, the distance to be maintained is the same. The distance shall not be less than 26 inches nor more than 30 inches. Anything more than that will not draw in the cooking fume effectively as the chimney will not be able to take away all the smoke, heat, odor, and impurities completely out of the room. Anything less than 26 inches can block the use or view of pans and vessels while cooking.
Therefore, to avoid any major consequences and ensure the chimney works well, the distance shall be maintained anywhere between 26 inches to 30 inches.

Choosing the compatible & best Hood/Chimney for Your Kitchen to decide which type of hood works well for your kitchen, you have to consider the workspace, your cooking style, and personal preferences.
The following few points may help you to pick up the good choice for your kitchen

Flexibility:

You can choose between ducted or ductless kitchen hood if you have ducts in your kitchen, else going for a ductless one will be the only option. Generally, a ductless hood will offer more flexibility. The type of hood you can have will also depend on where you are planning to put your kitchen range and cooktop.

Humidity and Air Quality in the Kitchen

You need a ducted hood if you have a humid kitchen. If you can manage with recirculating air and a bit of noise, a ductless hood will be fine.

Project Cost :

Installing ductwork that fits your duct range may be a little costly. If you are planning to replace an old one, it is easy to remain with your old one which you had before also saved your money & time .

In the last few words, it totally depends on your choice what you select, a ducted or ductless kitchen hood. Ducted may offer better efficiency in most scenarios, but ductless hoods can also work fine in a lot of arrangements. All you need to do is inspect & examine your options available and consider the pros and cons of both.

Entrust a Professional

Usually, unless you understand and can differentiate between the different kinds of Kitchen Chimney types and installation limitations, it becomes impossible to source the modular kitchen essentials for your home. We, Home Appliances Bazar help to make your decision easy for you by providing the service with clear & transparent pricing.
